VKEFOT TB 43x57x9 mm NBR Flanged Metal Shell Rotary Shaft Oil Seal with Dust Lip Waterproof Mudproof
Model / SKU: VKEFOT-TB-43-57-9
VKEFOT TB 43x57x9 mm radial shaft oil seal, NBR nitrile rubber, flanged carbon steel metal shell with integrated dust lip. Factory direct supply from Xingtai, China. Working temperature -35℃ ~ +100℃, max pressure ≤0.05MPa, excellent waterproof, mudproof and anti-deformation performance. Designed for automotive rotary shaft sealing, protects bearings from mud, splash water and dust ingress. Send RFQ with quantity and destination for quotation.
Tags: VKEFOT TB oil seal, TB 43x57x9 rotary shaft seal, 43-57-9 NBR flanged metal shell oil seal, waterproof mudproof TB seal with dust lip, automotive shaft oil seal replacement
Product photos
Key specs: Inner diameter mm: 43 | Outer diameter mm: 57 | Height mm: 9 | Material: NBR | Size: 43×57×9 mm | Type: TB Oil Seal | Material: NBR Nitrile Rubber + AISI1010 Carbon Steel Shell | Structure: Flanged Metal Shell, Spring Energized Lip + Dust Lip
- Inner diameter mm: 43
- Outer diameter mm: 57
- Height mm: 9
- Material: NBR
- Size: 43×57×9 mm
- Type: TB Oil Seal
- Material: NBR Nitrile Rubber + AISI1010 Carbon Steel Shell
- Structure: Flanged Metal Shell, Spring Energized Lip + Dust Lip
- Temp Range: -35℃ ~ +100℃
- Max Pressure: ≤0.05MPa
- Max Shaft Speed: ≤12m/s
- Medium: Mineral Oil, Grease
Technical summary
Product specifications. Refer to the approved drawing for dimensional tolerances and installation requirements.
| Spec | Value |
|---|---|
| Size | 43×57×9 mm |
| Type | TB Oil Seal |
| Material | NBR Nitrile Rubber + AISI1010 Carbon Steel Shell |
| Structure | Flanged Metal Shell, Spring Energized Lip + Dust Lip |
| Temp Range | -35℃ ~ +100℃ |
| Max Pressure | ≤0.05MPa |
| Max Shaft Speed | ≤12m/s |
| Medium | Mineral Oil, Grease |
| Application | Automotive Rotary Shaft Sealing |
Pricing: request a quote (B2B / wholesale).
MOQ / commerce notes: MOQ: 100–5000 pcs | Lead Time:7–15 working days
Product details
VKEFOT TB type 43x57x9 mm radial rotary shaft oil seal manufactured in Xingtai, China. TB is a classic flanged metal skeleton oil seal defined by ISO Type5 standard. The flanged carbon steel outer shell provides axial positioning and high rigidity, resisting deformation during assembly and vehicle operation.
This TB seal adopts spring-energized primary sealing lip plus built-in dust lip. NBR nitrile rubber delivers stable sealing against mineral oil and bearing grease. The dust lip effectively blocks mud, sand and splash water from entering the bearing cavity, ideal for dusty and wet working environments. Max working pressure ≤0.05MPa, allowable shaft speed up to 12m/s, operating temperature -35℃ to +100℃. Widely used for automotive rotary shaft overhaul, aftermarket replacement for vehicle shaft sealing and light machinery maintenance.
Key Features
- TB ISO Type5 flanged metal shell radial shaft oil seal, dimension 43×57×9 mm
- Rigid AISI1010 carbon steel flange housing, good anti-deformation property
- Spring loaded main lip + integrated dust lip, waterproof and mudproof
- NBR nitrile rubber, compatible with mineral oils and lubricating greases
- Aftermarket replacement for automotive rotary shaft sealing applications
Material & Working Condition
Base rubber material is NBR (Nitrile Butadiene Rubber). Compatible with mineral oils and greases. Not suitable for ester oils, brake fluid and strong chemical solvents. Confirm lubricant type and operating temperature in your RFQ.
Typical Applications
Automotive rotary shaft sealing, light machinery shaft sealing. This is an aftermarket replacement seal. Verify shaft diameter and housing bore dimension before purchase.
Installation Guide
- Clean shaft journal and housing bore thoroughly, remove old seal residue, rust, burrs and contaminants.
- Lightly lubricate sealing lip with compatible oil or grease before fitting.
- Press TB seal evenly and squarely into the bore until flange face fully sits against housing surface, avoid tilting.
- Prevent scratches or nicks on rubber lip during installation; lip damage will cause oil and grease leakage.
- After assembly, perform leak inspection before full load operation.
Packaging & Shipment
- Standard packing：neutral plastic bags + export cartons, packing quantity adjustable as requested.
Samples are available for standard stocked sizes; sample freight cost confirmed during RFQ.
VKEFOT is a professional manufacturer of rotary shaft oil seals and custom rubber sealing components in Xingtai, China. Our products are exported to Europe, North America, Middle East and Southeast Asia. Send RFQ including seal size, quantity, destination country and working medium for formal quotation.
Need help specifying a seal?
Use these checks to prepare your enquiry. Final suitability depends on the specific design and operating conditions.
Check dimensions and design
Provide the shaft diameter, housing bore and seal width in mm. Include the part marking, lip profile or a dimensioned drawing if available.
Describe operating conditions
Share the fluid or medium, operating temperature, pressure and shaft speed. Confirm the material grade against the application.
Verify a replacement
Provide the original part number and photos. Similar dimensions alone do not confirm interchangeability; compare the design and material.
FAQ
What is VKEFOT TB 43x57x9 oil seal used for?
This TB 43×57×9 mm flanged metal shell radial shaft oil seal is used for automotive rotary shaft sealing. It retains lubricant and blocks mud, dust and splash water to protect bearings.
What is TB type oil seal?
TB oil seal is ISO Type5 radial shaft seal with flanged metal outer shell, spring energized sealing lip and built-in dust lip. The flange provides axial positioning during installation for automotive and light machinery.
What is the temperature range for TB 43x57x9 NBR oil seal?
Working temperature range: -35℃ to +100℃, max working pressure ≤0.05MPa, maximum allowable shaft speed up to 12 m/s, compatible with mineral oil and grease.
What material is TB 43x57x9 oil seal made of?
NBR nitrile rubber sealing lip with AISI1010 cold rolled carbon steel flanged metal shell. Alternative compounds FKM, HNBR and ACM are available upon request.
Does TB 43x57x9 oil seal have dust lip?
Yes, this TB seal comes with integrated dust lip, effectively blocking mud, sand and splash water to extend bearing service life in wet and dusty environments.
What are the advantages of TB flanged oil seal compared to TC seal?
TB has outer flange for axial positioning, not easy to shift during assembly; TC is plain metal shell without flange. TB is preferred for applications requiring mud and water exclusion.
How to install TB flanged metal shell oil seal correctly?
Clean shaft and housing bore, lightly lubricate sealing lip, press seal squarely until flange sits flat against housing surface, avoid scratching the rubber lip.
What is MOQ and lead time for VKEFOT TB oil seal?
MOQ:100–5000 pcs, lead time:7–15 working days. Final quantity and delivery time confirmed on formal quotation.
What information should I provide for RFQ to VKEFOT?
Please provide seal dimension, type, quantity, destination country and working medium for accurate quotation.
