70x95x12mm TC double‑lip Oil Seal For Rotary Shaft Industrial & Automotive Aftermarket

70x95x12mm TC double‑lip Oil Seal For Rotary Shaft Industrial & — main photo

This aftermarket TC double‑lip oil seal measures 70x95x12mm and is constructed from FKM compound. It delivers rotary shaft sealing performance for importers, wholesalers and repair networks with lead time 7‑15 working days.

Tags: 70x95x12mm, TC double‑lip rotary shaft, FKM oil seal, Industrial shaft seal, Rotary Shaft Oil Seal

Product photos

70x95x12mm TC double‑lip Oil Seal For Rotary Shaft Industrial & — photo 2 70x95x12mm TC double‑lip Oil Seal For Rotary Shaft Industrial & — photo 3 70x95x12mm TC double‑lip Oil Seal For Rotary Shaft Industrial & — photo 4

Key specs: Inner diameter mm: 70 | Outer diameter mm: 95 | Height mm: 12 | Material: FKM | Spec & Model: FKM | Spec & Model: TC double‑lip | Spec & Model: 70x95x12mm | Material: FKM

  • Inner diameter mm: 70
  • Outer diameter mm: 95
  • Height mm: 12
  • Material: FKM
  • Spec & Model: FKM
  • Spec & Model: TC double‑lip
  • Spec & Model: 70x95x12mm
  • Material: FKM
  • Structure: TC double‑lip
  • Spec & Model: 70x95x12mm

Technical summary

HTML summary for crawlers. PDF/CAD attachments remain authoritative for drawings; download on the interactive product page.

SpecValue
MaterialFKM
StructureTC double‑lip
规格型号70x95x12mm

Pricing: request a quote (B2B / wholesale).

MOQ / commerce notes: Lead time 7–15 working days

Request a quote · Inquiry · Request a sample

Product details

This aftermarket replacement TC double‑lip oil seal is dimensioned 70x95x12mm, built with metal case and garter spring for rotary shaft sealing applications, constructed with FKM fluorocarbon rubber compound. Targeted at importers, wholesalers and repair networks, this rotary shaft seal retains lubricants and blocks dust, moisture and grit contamination. Send inquiry including size, reference specs, quantity and destination for formal quotation, lead time 7‑15 working days. Features & Benefits TC double‑lip profile blocks dust, water and particulate intrusion Integrated garter spring maintains consistent lip contact pressure FKM compound for high‑temperature and chemical resistance Precision formed steel skeleton supports housing installation Robust bonding between rubber and metal shell Aftermarket replacement for rotary shaft sealing Factory standard options, confirm on RFQ Suited for bulk stock and repair network replenishment Material & Process Sealing lip ：FKM fluorocarbon rubber; reinforcing skeleton: cold‑rolled steel; garter spring: carbon steel. Vulcanized bonded construction. Typical operating temperature range:‑20℃ to +200℃, confirm compound grade with RFQ. NBR compound upgrade available upon request, subject to quotation. Applications & Compatibility Commonly listed for general‑purpose industrial rotary shafts, motors, reducers and general equipment, retains gear oil and equipment lubricants. Resists high‑temperature oils and certain chemical media. Not intended for strong polar solvent exposure. Aftermarket replacement. Verify shaft diameter, housing bore and dimension specs before order. Selection & Installation Selection Tips Cross‑check shaft OD, housing bore ID and seal width 70x95x12mm prior to purchase. Commonly listed fitments do not guarantee direct fitment. Confirm compound grade with RFQ for extreme working conditions. Installation Steps 1. Thoroughly clean shaft and housing bore to remove burrs, metal chips and old seal residue. 2. Lubricate sealing lip; never perform dry installation. 3. Confirm correct seal orientation, double‑lip side faces contaminant side. 4. Apply uniform vertical press‑in force, use proper installation tool. 5. Do not strike rubber lip area with hammer or hard tool. 6. Press seal fully seated against housing shoulder. 7. Rotate shaft by hand after mounting to confirm free movement. Packaging & Delivery Neutral poly bag inside export carton. Typically 50‑200 pcs per carton, adjustable. Lead time 7‑15 working days. Sample and mixed sizes accepted. Payment and Incoterms confirmed on quotation (see trade policy). Documents on request: commercial invoice, packing list, certificate of origin. Send an inquiry with size, OE, quantity and destination for a firm lead time.

FAQ

There are only competing products—OEM and model—but not your part number. Can we use them as a reference for selection?

Sure. Please include the competing products/OEM model, key dimensions (ID × OD × height, in mm), and operating conditions (medium, temperature, pressure, rotational speed) to the inquiry form, and we will match them with equivalent specs items in our catalog.If dimensions are unavailable, please send model and photos/drawing first, and we will confirm the details. The final model selection will be based on the confirmation of drawing and operating conditions, and the official quotation will be subject to the written quotation order.

Does it support OEM/ODM along with privatization of packaging and tagging?

We support performing OEM/ODM in accordance with drawing/sample, as well as packaging and marking customization within the agreed upon scope.Please provide details on the target market’s compliance requirements and estimated annual volume. During the RFQ phase, we will confirm process feasibility, tooling costs, and mass production cycle time.

What is this 70x95x12mm TC double‑lip seal used for?

This 70x95x12mm TC double‑lip FKM oil seal provides rotary shaft sealing, retains lubricant and blocks dirt ingress for industrial equipment and aftermarket maintenance.

What are the specs and material for TC‑70‑95‑12‑FKM oil seal?

Dimension 70x95x12mm, structure TC double‑lip, base material FKM fluorocarbon rubber, confirm compound grade with RFQ for extreme working conditions.

What equipment fits 70x95x12mm TC‑FKM oil seal?

Commonly listed for industrial rotary shafts, motors and reducers, verify shaft diameter and housing bore before order to avoid mis‑fit.

Can I get custom options for TC‑70‑95‑12‑FKM oil seal?

Factory standard pack, confirm on quotation, lead time 7‑15 working days for any special requirements.

What is MOQ and delivery for TC‑70‑95‑12‑FKM oil seal?

Lead time 7‑15 working days. Quantity confirmed on quotation.

How to prevent oil seal leakage during installation?

1. Clean shaft and housing completely; 2. Lubricate lip before mounting, avoid dry install; 3. Press vertically with tool, do not strike rubber lip.

What is shelf life for FKM 70x95x12mm oil seal?

Under dry and shaded storage condition, typical shelf life reaches about 24 months for this FKM 70x95x12mm oil seal.

What advantages does FKM bring to 70x95x12mm rotary shaft seal?

This 70x95x12mm FKM oil seal delivers typical high temperature and chemical resistance, confirm compound grade with RFQ for your working scenario.

What export documents can you provide for bulk seal order?

Commercial invoice, packing list and certificate of origin can be provided on request for orders with lead time 7‑15 working days.

Do you accept mixed‑size seal shipment for importers?

Sample and mixed sizes are accepted for this item, submit inquiry with size list, quantity and destination for details.
